Expanded PTFE gasket sheet is made of 100% expanded P.T.F.E. by using special process that produces a uniform and highly fibrillated microstructure with a great lot of fibers running in multidirection. These create a soft and pliable, yet very tough gasket that has excellent resistance of pressing, creep relaxation and cold flow....
Send InquiryExpanded PTFE sheet possesses universal resistance against common chemicals, except melted alkali metal, fluorine at liquid and gas states. It can be stored without any time limits and can seal uneven and damaged flanges
- full chemical resistance like solid sintered PTFE
- resistance against acids and bases of pH 0 to 14
- UV-resistant
- no aging, unlimited shelf life
- nontoxic, biologically inert
- non flammable
Specification
Specification of expanded ptfe sheets
Model | Thickness (mm) | Tolerance (mm) | Size (mm) | Tolerance (mm) |
WXXJ-05-E | 0.5 | ±0.10 | 1500X1500 | ±10 |
WXXJ-10-E | 1.0 | ±0.15 | ||
WXXJ-15-E | 1.5 | ±0.20 | ||
WXXJ-20-E | 2.0 | ±0.20 | ||
WXXJ-30-E | 3.0 | ±0.30 | ||
WXXJ-40-E | 4.0 | ±0.30 | ||
WXXJ-50-E | 5.0 | ±0.30 | ||
WXXJ-60-E | 6.0 | ±0.30 |
Product Features
Special Features
• best adaptation on uneven surfaces and affected sealing faces
• for sealing of stress sensitive material like glass lined steel, glass, ceramic*
• long lasting gasket solution for extreme aggressive Media
Suitable for use against :-
Acids Alkalis Corrosive Fluids Oils Solvents
For use in the following industries
Food & Beverage Pharmaceutical Chemical Petrochemical Distillery
Marine Power Generation Paper
Physical Properties of expanded ptfe sheets
Length Tensile Strength | 17.0MPa |
Cross Tensile Strength | 17.0MPa |
Compressive Strength | 17.0MPa |
Max Compressive Strength | 17.0MPa |
Gravity | 0.65~0.95g/cm³ |
Compression | WXXJ 45% JB/T10688-2006 40%~50% |
Recovery | WXXJ 15% JB/T10688-2006 >10% |
Leakiness (cm³/s) | WXXJ 0.1~0.2x10-4 JB/T10688-2006 <0.1x10-3 |
Temperature | -240~260°C |
Product Application
Expanded PTFE Sheet is a high performance sheet gasket material made of multi-directionally expanded virgin PTFE. It is a soft, form-in-place gasket material that conforms to almost any sealing surface. It is capable of withstanding a wide range of pressure, temperature and chemical environments. Due to its highly fibrillated microstructure, it has excellent creep resistance compared with other PTFE products.
Typical Application
> Distilleries, petrochemical, food and beverage, pharmaceutical, general chemical, power generation, iron and steel manufacturing, pulp and paper, etc.
Product Packaging
(1)Packed by plastic bags,put into Plywood cases that don't need fumigation. Other packing is customized according to client's requirements.
(2)PTFE surface treated should be kept in dark place, can not be damaged.
Please send us your requirement by email.
